Four Rollers Pneumatic Desktop Plastic Bottle Capping Machine

Main technical parameters: 1.Power Voltage:AC220/50Hz 2.Cap Diameter:¢16-¢55MM 3.Capping speed:20-50PCS/min 4.Applied bottle height:40-330MM

Send Inquiry


Four Rollers Pneumatic Desktop Plastic Bottle Capping Machine


Main technical parameters:
1.Power Voltage:AC220/50Hz
2.Cap Diameter:¢16-¢55MM
3.Capping speed:20-50PCS/min
4.Applied bottle height:40-330MM
5.Air compressure:0.4-0.6Kgf/cm
6.Weight:25Kg
7.Size:48(L)X40(W)X60(H)CM


Operation Precautions:
1.Before using, add ISOVG32 pneumatic gas oil or equivalent oil on the gas source processor.
2.To adjust the capping head according to the bottle height.
3.To adjust the cap size, according to the bottle cap, two sides adjust at the same time.
4.To adjust the position withstand, let the bottle mouth under the center of the capping head.
5.To adjust the Torque regulator meet capping strength.
6.Switch on the power, open the hand sliding switch for gas.
7.Control valve operation, first to pull up the adjustment switch can adjust the air pressure.
8.Manual operation, to connect the food stamp switch under the electric box. Note: To be sure the manual/ automatic button on the red light position.


Yeto Machine is a professional manufacturer and supplier of various machine. Please rest assured to buy the high-end four rollers pneumatic desktop plastic bottle capping machine with competitive price from us. We will offer you good after-sale service and fast delivery.
