Vertical High Accuracy One Head Thermostatic Mixing Filling Machine

This unit is developed on the basis of the new design, and increase some additional function according to overseas similar products. filler is in reference and...

Send InquiryChat Now


Vertical High Accuracy One Head Thermostatic Mixing Filling Machine


This unit is developed on the basis of the new design, and increase some additional function according to overseas similar products. filler is in reference and an increase of some additional features. It is more simplified and more convenient for the operation. precision adjustment. filling volume adjustment. equipment cleaning. maintenance of the products, etc.
This unit adopts pneumatic components to replace electrical control circuit, so it is quite suitable for the use in the request of anti-explosion environment




II.Model selected
The model of the filling machines which made by our factory is according to the maximum filling volume of the customer's request.

Specific models:
TVFA1- 6             (5-60ml)
TVFA1-12            (15-120ml)
TVFA1-25            (60-250ml)
TVFA1-50            (100-500ml)
TVFA1-100          (100-1000ml)
TVFA1-250          (500-2500 ml)
TVFA1-500          (500-5000 ml)


III.Work principle
A.Through the cylinder's movement of forward and backward to make the piston which is located in the cylinder do reciprocating movement, so as to occur the negative pressure in the preceding chest of the cylinder
B.The piston is pulled backward when the cylinder make forward movement, the material cylinder occurred negative pressure, the materials in the barrel are pressed into the feeding pipe by pressure and go into the material pipe through unidirectional valve of feeding and discharging materials.
C.The piston is driven forward when the cylinder make backward movement, the materials are pressed. and go into discharging pipe through unidirectional valve of discharging materials, finally filled into the empty bottle which need to be filled,then one time filling finished.
D.It is a single and simple action to each time of filling for the piston filling machine, so it has very high filling precision and stability to every regular container

IV.Feature
A.All adopt compressed air as the control, so they are quite suitable for the use in the request of anti-explosion environment, has high safety.
B.Does not occur the phenomenon of static electricity, the leakage of electricity and no need to connect the ground wire
C.All adopt pneumatic control besides hardware positioning, so they have high filling precision as the precision can be controlled within 0.5%.
(with the greatest amount of filling as standards)


heating filling machine  (3).png


Yeto Machine is a professional manufacturer and supplier of various machine. Please rest assured to buy the high-end vertical high accuracy one head thermostatic mixing filling machine with competitive price from us. We will offer you good after-sale service and fast delivery!
