Small Power Hand Hold Homogenizer Dispenser Mixer for Cosmetic Cream Lotion

Technical specifications of production vacuum emulsification mixer Applications of production vacuum emulsification blender • Cosmetics & Toiletries: cream...

Send Inquiry


Small Power Hand Hold Homogenizer Dispenser Mixer for Cosmetic Cream Lotion


 Homogenizer Dispenser Mixer for Cosmetic Cream Lotion

Applications of production vacuum emulsification blender
• Cosmetics & Toiletries: cream, lotion, wax, mascara, gel, toothpaste
• Pharmaceuticals: ointment, dental composite, syrup, injection
• Food: mayonnaise, dressing, jam, butter, margarine, wasabi
• Chemicals: polyester, synthetic fiber, shoe cream

Options of production vacuum emulsification plant
• Fixed cover with bolts or welding to save budget
• Frame type slow agitator for oil pre-mixer
• Delta, Schneider or Siemens PLC for automation of mixing, dispersing, emulsifying, homogenizing, vacuum, transferring, heating and cooling etc
• Mettler-Toledo load cells
• Flow meter automation for feeding liquid oil and water
• Pressure vessel design for different steam pressure
• SIP is available upon request
• Different power supply acceptable.




• Complete process of mixing, dispersing, emulsifying, homogenizing, vacuum, heating and cooling in one unit

• Working capacity from 50L to 2000L
• Suitable for cream and emulsions of 10,000~50,000cps viscosity
• Internal emulsifying and homogenizing by top mounted batch homogeniser
• Contra mixing system of center agitator and wall scraper
• Outer frame agitator has triangle design for enhanced mixing
• Variable speed for homogenizer and agitators
• Oil hydraulic lifting system for easy cleaning and maintenance
• Double jackets for heating and cooling
• Different jacket designs available for steam and electric heating
• Double temperature probes and controllers for electrical heating in main emulsification machine
• Vacuum system to take out the air bubbles during mixing and to transfer the ingredients
• Compressed air to discharge the finished cream
• Tilting system for discharging finished product and easy cleaning
• Multiple safety protection devices for vacuum, hydraulic pump and workers
• All contact parts are made of SS316L and mirror polished
• Spray ball is equipped to connect customer’s CIP
• The specifications of the vacuum emulsification equipment comply with cGMP regulations
• Push buttons control panel for easy operation
• Power supply of 380V, 50Hz, 3 Phase


Yeto Machine is a professional manufacturer and supplier of various machine. Please rest assured to buy the high-end small power hand hold homogenizer dispenser mixer for cosmetic cream lotion with competitive price from us. We will offer you good after-sale service and fast delivery.
