Automatic flat square round bottle jar can labeling machine
one machine can realize single-sided and double-sided labeling of four products (round bottle, flat bottle, square bottle, shaped bottle);
It adopts double-sided rigid plastic synchronous guiding chain to ensure the neutrality of the bottle automatically. It has low requirements for the worker to put the bottle and the assembly line into the bottle, which greatly reduces the difficulty of docking the workers or the assembly line. It can be produced in a single machine or in the production line.
Technical parameter:
1. Applicable label length (mm): 20mm ~ 300mm
2. Applicable label width (bottom paper width / mm): 20mm ~ 170mm
3. Applicable product size:
length (conveying direction): 20mm ~ 250mm
Width (transport width direction):30mm ~ 90mm
Height: 60mm ~ 280mm
4. Applicable standard roll outer diameter: 290mm
5. Applicable standard inner diameter: 76mm
6. Labeling accuracy: ±1.0mm (excluding product, label error)
7. Marking speed (m/min): Servo: 5~40m/min
8. Labeling speed: Servo: 50~200pcs/min
conveying speed (m/min): 16m/min
9. Power (W): 1600W , AC 220V/50Hz
