Automatic powder particle granule powder filling capping sealing machine
The semi-automatic filling and packaging machine can complete metering, filling, etc. Due to the unique design, it is even more suitable for packaging those powdery and granular materials that are easy to flow or have poor fluidity, such as veterinary drugs, powdered additives, carbon powder, talcum powder, pesticides, flavors and fragrances.
Features:
1.The appearance of the whole machine is made of stainless steel except the motor and the tripod; the hanging material box can be easily disassembled and cleaned without tools.
2.The servo motor is used to control the screw, which has the advantages of high precision, fast speed, large torque and long life.
3.Touch screen display, the packaging weight can be adjusted steplessly at any time, the working state can be changed at any time, and the operation is convenient.
4.Designed as a weighing feedback specific gravity tracking type, it overcomes the shortcomings of changes in packaging weight due to changes in the specific gravity of materials.
Replacement of spiral accessories can adapt to a variety of materials from ultra-fine powder to small particles
Optional: install a centrifugal device for the flow of good material outlets to ensure accuracy, and install a dust suction device for the dusty material outlets to suck back dust.
Name Semi-automatic powder machine
Measuring method: weighing feedback tracking spiral rotary filling type
Packing weight 1-5000g (change screw parts, customize screw length and diameter according to requirements)
Measurement accuracy deviation≤±1% (specifically subject to material)
Filling speed depends on the speed of hands and feet for manual bagging or bottle placement
Power supply 380V 50/60Hz
Total power 2 KW
Total weight about 130kg
Overall volume: 930×980×1900 mm
Material box volume 50L
