pocket perfume bottle filling machine machine for sale
This filling machine is mainly used for filling perfume and essential oil, with high filling accuracy, easy to adjust the filling parameters . Each filling head can be sperately controlled and filled, no bottle no filling , it can keep all the filling at same liquid level.
Advantage :
High filling accuracy : 0.5%
It can adopt any shaped bottles, no need bottle mold.
PLC touch screen, easy to set the filling parameters.
Electric-eye sensor keep the filling at same liquid level.
We provide one year warranty .
We also can provide a complete perfume production line equipments, such as stainless steel storage tank, mixing freezing machine, filling machine, pump cap crimping machine, collar cap pressing machine .
Details:
Technical parameters:
Bottle height | ≤250mm |
Applicable bottle body diameter | ≤φ90mm |
| Maximum diameter | ≤φ20mm |
Minimum diameter | ≥4.5mm |
Applicable diameter for bottle mouth | ≥5mm |
Filling speed | 40 bottles/min |
Filling heads | 4 heads |
Air pressure | 0.4Mpa |
Dimension | 70cm*60cm*165mm |
Air extraction rate | 5.5 |
